After I wrote about migrating Apple ADE enrollment profiles to the new enrollment policies, someone asked me on LinkedIn whether the recreation step could be scripted. The article covers that part manually: open the wizard, tick through every Setup Assistant screen, one profile at a time. That’s fine for a single token with two or three profiles. It stops being fine once you’re doing it across several enrollment program tokens with iOS and macOS profiles on each.
So I wrote New-AdePolicyFromProfile.ps1 - a script that reads an existing classic enrollment profile and creates the equivalent Settings Catalog enrollment policy via Microsoft Graph, field by field, instead of clicking through it.
What It Does
The script copies every classic profile field that has a direct equivalent on the new policy: user affinity and the Intune authentication method, locked enrollment, the device name template, department/phone, every Setup Assistant screen toggle that still exists, and - for macOS - the full nested local admin / primary account tree.
Two categories of fields don’t get a straight copy:
- Policy-only fields - screens like Action Button, Terms of Address, Intelligence, or App Store never existed on the classic profile, so there’s nothing to copy from. These get set to a default (Hide or Show, your choice) instead.
- Profile-only fields - things like Supervised mode, Shared iPad, session timeouts, or Apple Configurator certificates have no equivalent on the new policy at all. These are left out and listed in the script’s summary output so you know what to configure manually afterwards.
The script only creates the policy. It doesn’t assign it, set it as default, or touch existing devices - those stay separate, deliberate steps, same as in the manual walkthrough.
Single Profile or Bulk
# One profile
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]'
# Every classic profile on one token
.\New-AdePolicyFromProfile.ps1 -TokenName 'Intune PI Dev SST'
-ProfileName alone (optionally narrowed with -TokenName) targets a single profile. -TokenName on its own switches to bulk mode and migrates every classic profile still sitting on that token, skipping anything that’s already a Settings Catalog policy so re-runs don’t create duplicates of duplicates.
New policy names are derived automatically from my naming convention: DeploymentProfile in the old name becomes EnrollmentPolicy. If a profile doesn’t follow the convention, single mode lets you override the name explicitly with -NewPolicyName, or reuse the old name as-is with -AllowIdenticalName. In bulk mode there’s no way to supply a name per profile, so non-conforming profiles are skipped with a warning unless -AllowIdenticalName is set, in which case they get migrated under their existing name unchanged.
Device Group - Single Mode Only
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]' -DeviceGroupName 'MDM-iOS-ADE-Assigned'
-DeviceGroupName sets the policy’s enrollment-time device group - the headline feature from the previous article. It only works in single mode. In bulk mode there’s no reliable way to know which group belongs to which profile without guessing, so I left it unsupported there rather than build something that silently assigns the wrong group.
This setting turned out to be the trickiest part of the whole script, for two reasons:
It fails silently without the right permissions. If the signed-in account or app doesn’t have sufficient rights on the target group (Owner, in practice), the Graph call that sets the group returns success anyway - the policy gets created, just without the group attached, and nothing tells you that happened. The script now double-checks by calling retrieveEnrollmentTimeDeviceMembershipTarget after the fact and warns explicitly if the group didn’t take.
There’s no obvious way to read it back. The property I expected to hold the answer - enrollmentTimeAzureAdGroupIds on the classic profile mirror - turned out to be a leftover from an older concept and stays empty regardless. Neither isAssigned nor the policy’s /assignments collection reflects it either. The actual readback is retrieveEnrollmentTimeDeviceMembershipTarget, a function on the policy that isn’t discoverable from the Graph documentation or schema search - I only found it by capturing what the Intune portal itself calls when it shows you the device group tab, using Graph X-Ray, a browser extension that turns portal clicks into the underlying Graph API calls.
New-Only Fields Default to Hide
.\New-AdePolicyFromProfile.ps1 -ProfileName 'Old iOS Profile' -NewFieldDefault Show
Fields that only exist on the new policy - Action Button, Emergency SOS, Terms of Address, Intelligence, Lock Down Mode, App Store, and a handful of others depending on platform - have nothing on the old profile to copy from. By default the script hides them, matching what you’d get by leaving them untouched in the policy wizard. Pass -NewFieldDefault Show to flip that default for the whole run if you’d rather have them visible.
Re-Running Safely
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]' -WhatIf
Before creating a policy, the script checks whether one with the target name already exists and asks whether to create a duplicate anyway. -Force skips that prompt if you genuinely want a duplicate (for example, while iterating on -NewFieldDefault). -WhatIf is supported throughout for a dry run.
Notes
A few things worth calling out if you’re reading the script or adapting it:
- The
settingInstanceTemplateId/settingValueTemplateIdpairs hardcoded into the script were read back from real policies created in a test tenant (POST, then GET), not guessed from documentation. While I was pulling these together with Claude, it flagged that the GUIDs Microsoft assigned to some of the newer Setup Assistant screens looked suspiciously patterned - too sequential to be genuine, more like placeholders than real identifiers. That was enough to make me double- and triple-check those specific ones against live tenant data before trusting them. - The macOS local admin / primary account settings form a nested tree that isn’t obvious from the classic profile’s flat property list.
createlocalprimaryis always nested undercreatelocaladminregardless of either one’s value;prefillaccountinfo(and the fields under it) only appears whencreatelocalprimaryisn’t “No”; and Graph requiresadminaccountpasswordrotationas a mandatory sibling the momentcreatelocaladminis “Yes” - leave it out and the policy creation fails with a 400. - Editing an existing Settings Catalog enrollment policy in the portal to add a primary account after creation can crash the properties editor (
Microsoft_Intune_Enrollment/PropertiesEditor.ReactViewfails to load). Setting every field at creation time, as this script does, avoids that path entirely.
The script is also available in my Intune-Misc GitHub repo, alongside the script from the previous article.
The Complete Script
#Requires -Version 7.2
#Requires -Modules Microsoft.Graph.Authentication
<#
.SYNOPSIS
Creates a new Apple ADE Settings Catalog enrollment policy that replicates
the settings of an existing classic enrollment profile.
.DESCRIPTION
Intune's classic enrollment profiles (depIOSEnrollmentProfile /
depMacOSEnrollmentProfile) are frozen - new Setup Assistant screens only
land in the newer Settings Catalog enrollment policies
(deviceManagement/configurationPolicies). Recreating a profile as a policy
by hand in the GUI is the first step of the migration, field by field.
This script automates that copy.
Every classic boolean/string field that has a direct policy equivalent is
copied across, including the nested macOS local admin / primary account
tree. Setup Assistant screens that only exist on the new policy
(Action Button, Terms of Address, Intelligence, etc.) have no source value
to copy, so they are set to -NewFieldDefault instead. Fields that have no
policy equivalent at all (Supervised mode, Shared iPad, session timeouts,
Apple Configurator certificates, admin password rotation, ...) are left
out and listed in the summary so you can configure them manually
afterwards.
The script creates policies directly via Graph, which sidesteps a known
Intune portal bug: editing an existing Settings Catalog enrollment policy
in the GUI to add a primary account afterwards can crash the properties
editor (Microsoft_Intune_Enrollment / PropertiesEditor.ReactView fails to
load). Setting the same fields at creation time, as this script does,
works fine.
The script only creates the policy - it does not assign it, set it as
default, or set an enrollment-time device group. Those stay separate,
deliberate steps.
.PARAMETER ProfileName
Display name of the classic enrollment profile to copy. Mandatory unless
-TokenName is given without it, in which case every classic profile on
that token is migrated.
.PARAMETER TokenName
Limit the run to a single enrollment program token. Mandatory if
-ProfileName is omitted (bulk mode); optional as a narrowing filter when
-ProfileName is given.
.PARAMETER NewPolicyName
Optional. Only valid together with -ProfileName. Overrides the
auto-derived policy name. Without it, the old profile name must contain
the naming convention's 'DeploymentProfile' segment (e.g.
'ABM-DeploymentProfile-iOS-...'), which is substituted with
'EnrollmentPolicy'. In bulk mode (-TokenName only), profiles whose name
doesn't follow the convention are skipped with a warning instead, unless
-AllowIdenticalName is set.
.PARAMETER AllowIdenticalName
When a profile's name doesn't contain the naming convention's
'DeploymentProfile' segment, create the new policy under the exact same
name as the old profile instead of erroring (single mode) or skipping it
(bulk mode).
.PARAMETER DeviceGroupName
Optional. Only valid together with -ProfileName (single mode) - a bulk
run has no reliable way to know which group belongs to which profile, so
it isn't supported there. Display name of an existing Entra ID security
group to set as the policy's enrollment-time device group. Must resolve
to exactly one group. The script verifies the assignment afterwards via
retrieveEnrollmentTimeDeviceMembershipTarget and warns if it didn't take
(e.g. the signed-in account/app lacks sufficient rights, such as Owner,
on the group).
.PARAMETER NewFieldDefault
'Show' or 'Hide' (default 'Hide'). Value applied to Setup Assistant
screens and other settings that exist only on the new policy and have no
classic profile field to copy from.
.PARAMETER Force
Skip the confirmation prompt and create the policy even if one with the
same name already exists (e.g. from a previous run). Without -Force, an
existing policy with the target name is reported and you're asked
whether to create a duplicate anyway.
.EXAMPLE
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]' -WhatIf
.EXAMPLE
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]'
.EXAMPLE
# Migrate every classic profile on one token, using the naming convention for all of them
.\New-AdePolicyFromProfile.ps1 -TokenName 'Intune PI Dev SST'
.EXAMPLE
# Also set the new policy's enrollment-time device group
.\New-AdePolicyFromProfile.ps1 -ProfileName 'ABM-DeploymentProfile-iOS-WithUser-ModernAuthentication-[PI-Baseline]' -DeviceGroupName 'MDM-iOS-ADE-Assigned'
.EXAMPLE
# Override the derived name for a single profile
.\New-AdePolicyFromProfile.ps1 -ProfileName 'Old iOS Profile' -NewPolicyName 'ABM-EnrollmentPolicy-iOS-WithUser-ModernAuthentication-[PI-Baseline]'
#>
[CmdletBinding(SupportsShouldProcess)]
param(
[string]$ProfileName,
[string]$TokenName,
[string]$NewPolicyName,
[switch]$AllowIdenticalName,
[string]$DeviceGroupName,
[ValidateSet('Show', 'Hide')]
[string]$NewFieldDefault = 'Hide',
[switch]$Force
)
Set-StrictMode -Version Latest
$ErrorActionPreference = 'Stop'
# PowerShell parameter sets can't express "TokenName alone means bulk mode"
# cleanly here: TokenName is a valid optional member of the single-profile
# set too, so binding only -TokenName is ambiguous between the two sets and
# PowerShell falls back to the default set, then prompts for the missing
# mandatory ProfileName instead of picking the bulk set. Validate manually.
if ([string]::IsNullOrWhiteSpace($ProfileName) -and [string]::IsNullOrWhiteSpace($TokenName)) {
throw 'Specify -ProfileName (optionally narrowed with -TokenName), or -TokenName alone to migrate every classic profile on that token.'
}
if ($NewPolicyName -and [string]::IsNullOrWhiteSpace($ProfileName)) {
throw '-NewPolicyName can only be used together with -ProfileName.'
}
if ($DeviceGroupName -and [string]::IsNullOrWhiteSpace($ProfileName)) {
throw '-DeviceGroupName can only be used together with -ProfileName (not in bulk -TokenName-only mode).'
}
$isBulkMode = [string]::IsNullOrWhiteSpace($ProfileName)
function Get-GraphAll {
param([string]$Uri)
$results = [System.Collections.Generic.List[object]]::new()
do {
$page = Invoke-MgGraphRequest -Method GET -Uri $Uri -OutputType PSObject
foreach ($item in $page.value) { $results.Add($item) }
$Uri = $page.PSObject.Properties['@odata.nextLink']?.Value
} while ($Uri)
return $results
}
function Get-DerivedPolicyName {
param([string]$OldName)
if ($OldName -match 'DeploymentProfile') {
return ($OldName -replace 'DeploymentProfile', 'EnrollmentPolicy')
}
return $null
}
# --- Settings Catalog metadata --------------------------------------------
# settingInstanceTemplateId / settingValueTemplateId pairs below were read
# back from real ADE policies created in the tenant (POST + GET round trip),
# not guessed from documentation - see the "Test ios" / "test mac" policies
# used to validate this script.
$iosTemplateId = '27d20e9c-50c1-48f8-a44c-f37de4510051_1'
$macTemplateId = '2e29557d-70fc-405a-8082-d1e5b6be2b8c_1'
$iosCatalog = @{
'ade_useraffinity' = @{ Inst = 'f3ddbbae-bb3d-45e8-bb9c-854f674e56ef'; Val = 'e34ab06d-486a-4cc0-a867-295515ac2dfc' }
'ade_lockedenrollment' = @{ Inst = 'e105d3a4-7318-454a-a231-0d1510ebf1e3'; Val = '49085612-4cce-4305-822d-6a6c793285be' }
'ade_devicenametemplatechoices' = @{ Inst = '93d1bf98-2345-468a-b0f0-1e2daf198357'; Val = '8c02396f-d58f-4275-be5c-dd97713d636e' }
'ade_activatecellulardatachoices' = @{ Inst = 'b63070e7-d6f7-44e7-b1c1-fd51615748a3'; Val = 'aaf7603d-0184-4143-bdfc-3326859ce0c3' }
'ade_setupassistant_department' = @{ Inst = '1fd43c7c-0c7a-4dcc-8392-7b1776f86d14'; Val = '180721e2-b467-40a3-b631-b2f28c5d9297' }
'ade_setupassistant_departmentphone' = @{ Inst = '383a4d4b-0bbc-4791-bc48-6def8716ec96'; Val = 'f7322d5b-07aa-4b5c-9846-bc3e547e7c0b' }
'ade_setupassistant_passcode' = @{ Inst = 'be808211-b4f1-4653-aa95-068b756dc682'; Val = '67b68eed-075f-4479-a34b-9ae3d2b1cf4d' }
'ade_setupassistant_locationservices' = @{ Inst = '5dca1893-31cd-49b7-aadf-c26990ea0639'; Val = '6f73700e-a14b-4784-9923-512a97297c41' }
'ade_setupassistant_restore' = @{ Inst = 'b4434e35-4131-4b13-90cb-4334cd9768dd'; Val = '78842c1b-d090-407d-9dec-a3a4a168a36f' }
'ade_setupassistant_appleid' = @{ Inst = '4f26cd1f-5fd1-4d6c-af69-f18ade85aee9'; Val = '469e5c1a-c2f8-44fb-b515-f8532c2dff40' }
'ade_setupassistant_termsandconditions' = @{ Inst = '5a33bd8e-9df4-422c-92f5-3d5294a3e015'; Val = '404a8266-5c46-44b3-bf63-d8974d91c8f9' }
'ade_setupassistant_touchfaceid' = @{ Inst = '0deedc8e-1597-47f0-a271-4ae5029c1795'; Val = 'f11533e6-85a1-41c3-b23d-7a7c0bc2f7f8' }
'ade_setupassistant_applepay' = @{ Inst = 'c7b005a7-148a-40b0-aa06-8a6eaafa6fc0'; Val = 'a18db77d-76e6-4bf8-ab60-98d1e34ed8df' }
'ade_setupassistant_siri' = @{ Inst = '764673c0-b331-478e-905f-ef45428fae99'; Val = 'f3c03777-e89d-4fbc-bc1a-75c4858fa579' }
'ade_setupassistant_diagnosticsdata' = @{ Inst = '6a6c0b44-8403-4213-8e34-fd21e416c0f3'; Val = '8e6986f8-3f2b-4a22-989d-08603dba0707' }
'ade_setupassistant_privacy' = @{ Inst = '129ac5ce-c6b8-4402-bf18-40045c11c10d'; Val = '177b8bd8-8dc1-4835-82af-16e81dc7e94f' }
'ade_setupassistant_androidmigration' = @{ Inst = 'ec192455-f753-4fe1-a4b5-ea98ce1f51a4'; Val = '55060cc0-c46b-40fa-9435-7adf473662fb' }
'ade_setupassistant_imessagefacetime' = @{ Inst = '53e650ca-9548-4fb6-8cba-3be4bc2d62a5'; Val = 'b1730b75-01d1-41a4-9e2e-d185ec2a5108' }
'ade_setupassistant_screentime' = @{ Inst = '90501450-54d9-4695-a16c-fbfead918c24'; Val = 'b1d1feea-8d71-49bb-8cf6-c736321ae9b6' }
'ade_setupassistant_simsetup' = @{ Inst = '7a270780-d94f-4d00-998e-2a5d69f43832'; Val = '8c2b8a4c-517a-47f7-9f05-392db533b05a' }
'ade_setupassistant_softwareupdate' = @{ Inst = '1ad911de-03ea-45a1-917e-adf9ececc09c'; Val = 'd9630ff4-94a4-4525-b37a-7c233a23a2bd' }
'ade_setupassistant_watchmigration' = @{ Inst = 'be182ec4-4e16-4f98-9ca2-e4775d35eb88'; Val = 'fe924b50-718f-4b7f-ac33-5a407ea0f005' }
'ade_setupassistant_appearance' = @{ Inst = '61b602c2-86a3-4bca-82e5-cc7e14e17895'; Val = '87067516-5437-44ce-a3cc-cee7b6518b46' }
'ade_setupassistant_devicemigration' = @{ Inst = '3243140d-97b7-42fe-ba57-f23f782f9112'; Val = '55900392-ff35-43dc-9adb-7fca1987a106' }
'ade_setupassistant_restorecompleted' = @{ Inst = '991507fe-fe61-41f9-b80c-cac3f071fb92'; Val = '14e4f24a-55d5-4c04-9f61-862cb42a90e9' }
'ade_setupassistant_softwareupdatecompleted' = @{ Inst = '8afaa22c-513a-41b4-9b49-1c888a6f1c53'; Val = '80bdf240-ad52-45fb-9a58-c888d812e75a' }
'ade_setupassistant_getstarted' = @{ Inst = '21017ab9-73d3-45dd-b715-8742791a5d73'; Val = 'df5a331d-7042-4abc-91f4-a37c82deaf08' }
'ade_setupassistant_actionbutton' = @{ Inst = '6f78e140-a99d-49a0-9658-0d5a4bb30726'; Val = '54fd9219-4c4a-4350-a2be-a85f1096f4da' }
'ade_setupassistant_safety' = @{ Inst = 'b8954ce1-36f1-4149-9851-99c050dfc3f8'; Val = '6290e656-2b8d-4793-b8fb-4336c64a32c5' }
'ade_setupassistant_termsofaddress' = @{ Inst = '5dbc8d66-d852-4188-9500-020956fbdfb7'; Val = '1f57641d-fd69-403e-b96d-4f60869e6d9d' }
'ade_setupassistant_intelligence' = @{ Inst = 'cca42541-0513-41a6-ae74-e1fe878b0593'; Val = 'd0c43d95-99c7-40ce-b3a6-33098215adc9' }
'ade_setupassistant_enablelockdownmode' = @{ Inst = '4a9db745-821d-44a1-a26a-06f2c637d8b8'; Val = '181a5e6d-df5c-4016-b484-3130d54ee9ab' }
'ade_setupassistant_appstore' = @{ Inst = 'b3c4d5e6-f7a8-9012-bcde-fa3456789012'; Val = 'a2b3c4d5-e6f7-8901-abcd-ef2345678901' }
'ade_setupassistant_camerabutton' = @{ Inst = 'd5e6f7a8-b9c0-1234-defa-bc5678901234'; Val = 'c4d5e6f7-a8b9-0123-cdef-ab4567890123' }
'ade_setupassistant_multitasking' = @{ Inst = 'f7a8b9c0-d1e2-3456-fabc-de7890123456'; Val = 'e6f7a8b9-c0d1-2345-efab-cd6789012345' }
'ade_setupassistant_osshowcase' = @{ Inst = 'b9c0d1e2-f3a4-5678-bcde-fa9012345678'; Val = 'a8b9c0d1-e2f3-4567-abcd-ef8901234567' }
'ade_setupassistant_safetyandhandling' = @{ Inst = 'd1e2f3a4-b5c6-7890-defa-bc1234567890'; Val = 'c0d1e2f3-a4b5-6789-cdef-ab0123456789' }
'ade_setupassistant_webcontentfiltering' = @{ Inst = 'f3a4b5c6-d7e8-9012-fabc-de3456789012'; Val = 'e2f3a4b5-c6d7-8901-efab-cd2345678901' }
}
$macCatalog = @{
'ade_macos_useraffinity' = @{ Inst = 'f3ddbbae-bb3d-45e8-bb9c-854f674e56ef'; Val = 'e34ab06d-486a-4cc0-a867-295515ac2dfc' }
'ade_macos_awaitconfiguration' = @{ Inst = '7e4d9c8a-2f5b-4a3c-8d9e-1b6a4f7c2e5d'; Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_createlocaladmin' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_createlocalprimary' = @{}
'ade_accountsettings_prefillaccountinfo' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_restrictediting' = @{}
'ade_accountsettings_primaryaccountfullname' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_primaryaccountname' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_adminaccountname' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_adminaccountfullname' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_hideusersgroups' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_accountsettings_adminaccountpasswordrotation' = @{ Val = '3a7c9d2e-8f4b-4e1a-9c5d-6b8a3f7e2d4c' }
'ade_lockedenrollment' = @{ Inst = 'e105d3a4-7318-454a-a231-0d1510ebf1e3'; Val = '49085612-4cce-4305-822d-6a6c793285be' }
'ade_setupassistant_department' = @{ Inst = '1fd43c7c-0c7a-4dcc-8392-7b1776f86d14'; Val = '180721e2-b467-40a3-b631-b2f28c5d9297' }
'ade_setupassistant_departmentphone' = @{ Inst = '383a4d4b-0bbc-4791-bc48-6def8716ec96'; Val = 'f7322d5b-07aa-4b5c-9846-bc3e547e7c0b' }
'ade_setupassistant_locationservices' = @{ Inst = '5dca1893-31cd-49b7-aadf-c26990ea0639'; Val = '6f73700e-a14b-4784-9923-512a97297c41' }
'ade_setupassistant_restore' = @{ Inst = 'b4434e35-4131-4b13-90cb-4334cd9768dd'; Val = '78842c1b-d090-407d-9dec-a3a4a168a36f' }
'ade_setupassistant_appleid' = @{ Inst = '4f26cd1f-5fd1-4d6c-af69-f18ade85aee9'; Val = '469e5c1a-c2f8-44fb-b515-f8532c2dff40' }
'ade_setupassistant_termsandconditions' = @{ Inst = '5a33bd8e-9df4-422c-92f5-3d5294a3e015'; Val = '404a8266-5c46-44b3-bf63-d8974d91c8f9' }
'ade_setupassistant_touchfaceid' = @{ Inst = '0deedc8e-1597-47f0-a271-4ae5029c1795'; Val = 'f11533e6-85a1-41c3-b23d-7a7c0bc2f7f8' }
'ade_setupassistant_applepay' = @{ Inst = 'c7b005a7-148a-40b0-aa06-8a6eaafa6fc0'; Val = 'a18db77d-76e6-4bf8-ab60-98d1e34ed8df' }
'ade_setupassistant_siri' = @{ Inst = '764673c0-b331-478e-905f-ef45428fae99'; Val = 'f3c03777-e89d-4fbc-bc1a-75c4858fa579' }
'ade_setupassistant_diagnosticsdata' = @{ Inst = '6a6c0b44-8403-4213-8e34-fd21e416c0f3'; Val = '8e6986f8-3f2b-4a22-989d-08603dba0707' }
'ade_setupassistant_filevault' = @{ Inst = '7d8e9c44-3b2a-4f13-8a5e-2c9d1b4f5a3e'; Val = '2f5c47e9-aa1b-4c35-9e8d-1fa2b8c3d7ea' }
'ade_setupassistant_iclouddiagnostics' = @{ Inst = '4c8a7d9e-2f5b-4a3c-9d8e-1b6a4f7c2e9d'; Val = '9a7d5c21-4e3b-4f8a-a9c6-7b5d3e1f2c4a' }
'ade_setupassistant_icloudstorage' = @{ Inst = '8f7d3c9a-4e2b-4d1a-9c8e-6b5a3d7f2e4c'; Val = '5b3e8a7c-9d2f-4a1c-8e5b-3d7a2f9c4e1b' }
'ade_setupassistant_appearance' = @{ Inst = '61b602c2-86a3-4bca-82e5-cc7e14e17895'; Val = '87067516-5437-44ce-a3cc-cee7b6518b46' }
'ade_setupassistant_screentime' = @{ Inst = '90501450-54d9-4695-a16c-fbfead918c24'; Val = 'b1d1feea-8d71-49bb-8cf6-c736321ae9b6' }
'ade_setupassistant_privacy' = @{ Inst = '129ac5ce-c6b8-4402-bf18-40045c11c10d'; Val = '177b8bd8-8dc1-4835-82af-16e81dc7e94f' }
'ade_setupassistant_accessibility' = @{ Inst = '9c7e4d8a-3f2b-4e1a-8d9c-5b7a3e6f2c4d'; Val = '3f8d7c9b-5e2a-4d1c-8f7e-2b9a5c6d3e1f' }
'ade_setupassistant_unlockwithwatch' = @{ Inst = '5c8e9d7a-4f3b-4d2a-8e9c-7b6a5d3f2e1c'; Val = '7e9d4c8a-2f5b-4e3c-9d8a-6b7c3e5f2a1d' }
'ade_setupassistant_enablelockdownmode' = @{ Inst = '4a9db745-821d-44a1-a26a-06f2c637d8b8'; Val = '181a5e6d-df5c-4016-b484-3130d54ee9ab' }
'ade_setupassistant_softwareupdate' = @{ Inst = '1ad911de-03ea-45a1-917e-adf9ececc09c'; Val = 'd9630ff4-94a4-4525-b37a-7c233a23a2bd' }
'ade_setupassistant_softwareupdatecompleted' = @{ Inst = '8afaa22c-513a-41b4-9b49-1c888a6f1c53'; Val = '80bdf240-ad52-45fb-9a58-c888d812e75a' }
'ade_setupassistant_termsofaddress' = @{ Inst = '21017ab9-73d3-45dd-b715-8742791a5d73'; Val = 'df5a331d-7042-4abc-91f4-a37c82deaf08' }
'ade_setupassistant_intelligence' = @{ Inst = 'cca42541-0513-41a6-ae74-e1fe878b0593'; Val = 'd0c43d95-99c7-40ce-b3a6-33098215adc9' }
'ade_setupassistant_osshowcase' = @{ Inst = '5d9c8e7a-3f2b-4d1a-8e9c-6b5a7d3f2e4c'; Val = '8c2d7f9e-4a3b-4e1c-9d8e-5b7a3c6f2d1e' }
'ade_setupassistant_appstore' = @{ Inst = '4c8e7d9a-3f2b-4d1a-9c8e-5b7a6d3f2e1c'; Val = '7e8d9c4a-2f5b-4e3c-8d9a-6b7c3e5f2a1d' }
}
# --- Setting instance builders ---------------------------------------------
function New-ChoiceInstance {
param(
[Parameter(Mandatory)][string]$DefId,
[Parameter(Mandatory)][string]$Value,
[string]$InstTplId,
[string]$ValTplId,
[array]$Children = @()
)
$inst = [ordered]@{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationChoiceSettingInstance'
settingDefinitionId = $DefId
}
if ($InstTplId) { $inst.settingInstanceTemplateReference = @{ settingInstanceTemplateId = $InstTplId } }
$csv = [ordered]@{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationChoiceSettingValue'
value = $Value
children = @($Children)
}
if ($ValTplId) { $csv.settingValueTemplateReference = @{ settingValueTemplateId = $ValTplId } }
$inst.choiceSettingValue = $csv
return $inst
}
function New-SimpleInstance {
param(
[Parameter(Mandatory)][string]$DefId,
$Value,
[string]$InstTplId,
[string]$ValTplId,
[ValidateSet('String', 'Integer')][string]$ValueType = 'String'
)
$inst = [ordered]@{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationSimpleSettingInstance'
settingDefinitionId = $DefId
}
if ($InstTplId) { $inst.settingInstanceTemplateReference = @{ settingInstanceTemplateId = $InstTplId } }
if ($ValueType -eq 'Integer') {
$ssv = [ordered]@{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationIntegerSettingValue'
value = [int]$Value
}
}
else {
$ssv = [ordered]@{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationStringSettingValue'
value = [string]$Value
}
}
if ($ValTplId) { $ssv.settingValueTemplateReference = @{ settingValueTemplateId = $ValTplId } }
$inst.simpleSettingValue = $ssv
return $inst
}
function New-TopLevelSetting {
param($Instance)
return @{
'@odata.type' = '#microsoft.graph.deviceManagementConfigurationSetting'
settingInstance = $Instance
}
}
# --- Classic field <-> Setup Assistant screen mapping ----------------------
$iosScreenMap = @(
@{ Field = 'passCodeDisabled'; DefId = 'ade_setupassistant_passcode' }
@{ Field = 'locationDisabled'; DefId = 'ade_setupassistant_locationservices' }
@{ Field = 'restoreBlocked'; DefId = 'ade_setupassistant_restore' }
@{ Field = 'appleIdDisabled'; DefId = 'ade_setupassistant_appleid' }
@{ Field = 'termsAndConditionsDisabled'; DefId = 'ade_setupassistant_termsandconditions' }
@{ Field = 'touchIdDisabled'; DefId = 'ade_setupassistant_touchfaceid' }
@{ Field = 'applePayDisabled'; DefId = 'ade_setupassistant_applepay' }
@{ Field = 'siriDisabled'; DefId = 'ade_setupassistant_siri' }
@{ Field = 'diagnosticsDisabled'; DefId = 'ade_setupassistant_diagnosticsdata' }
@{ Field = 'privacyPaneDisabled'; DefId = 'ade_setupassistant_privacy' }
@{ Field = 'restoreFromAndroidDisabled'; DefId = 'ade_setupassistant_androidmigration' }
@{ Field = 'iMessageAndFaceTimeScreenDisabled'; DefId = 'ade_setupassistant_imessagefacetime' }
@{ Field = 'screenTimeScreenDisabled'; DefId = 'ade_setupassistant_screentime' }
@{ Field = 'simSetupScreenDisabled'; DefId = 'ade_setupassistant_simsetup' }
@{ Field = 'softwareUpdateScreenDisabled'; DefId = 'ade_setupassistant_softwareupdate' }
@{ Field = 'watchMigrationScreenDisabled'; DefId = 'ade_setupassistant_watchmigration' }
@{ Field = 'appearanceScreenDisabled'; DefId = 'ade_setupassistant_appearance' }
@{ Field = 'deviceToDeviceMigrationDisabled'; DefId = 'ade_setupassistant_devicemigration' }
@{ Field = 'restoreCompletedScreenDisabled'; DefId = 'ade_setupassistant_restorecompleted' }
@{ Field = 'updateCompleteScreenDisabled'; DefId = 'ade_setupassistant_softwareupdatecompleted' }
@{ Field = 'welcomeScreenDisabled'; DefId = 'ade_setupassistant_getstarted' }
)
$iosNewOnlyDefIds = @(
'ade_setupassistant_actionbutton', 'ade_setupassistant_safety', 'ade_setupassistant_termsofaddress',
'ade_setupassistant_intelligence', 'ade_setupassistant_enablelockdownmode', 'ade_setupassistant_appstore',
'ade_setupassistant_camerabutton', 'ade_setupassistant_multitasking', 'ade_setupassistant_osshowcase',
'ade_setupassistant_safetyandhandling', 'ade_setupassistant_webcontentfiltering'
)
$iosSkippedFields = @(
"homeButtonScreenDisabled (Home Button screen removed from the new policy)"
"onBoardingScreenDisabled (Onboarding screen removed from the new policy)"
"expressLanguageScreenDisabled (Express Language screen removed from the new policy)"
"preferredLanguageScreenDisabled (Preferred Language screen removed from the new policy)"
"zoomDisabled (Zoom screen removed from the new policy)"
"displayToneSetupDisabled (Display Tone screen removed from the new policy)"
"supervisedModeEnabled (ADE devices are always supervised under the new policy)"
"enableSingleAppEnrollmentMode (no policy equivalent)"
"enableSharedIPad / sharedIPadMaximumUserCount (use the Shared iPad user affinity option manually)"
"iTunesPairingMode (no policy equivalent)"
"requireCompanyPortalOnSetupAssistantEnrolledDevices / companyPortalVppTokenId (handled automatically by modern authentication)"
"profileRemovalDisabled (tied to Supervised mode, always on for policies)"
"forceTemporarySession / temporarySessionTimeoutInSeconds / userSessionTimeoutInSeconds (no policy equivalent)"
"passcodeLockGracePeriodInSeconds (no policy equivalent)"
"carrierActivationUrl (no policy equivalent)"
"userlessSharedAadModeEnabled (no policy equivalent)"
"managementCertificates (Apple Configurator certificates must be re-added manually)"
)
$macScreenMap = @(
@{ Field = 'locationDisabled'; DefId = 'ade_setupassistant_locationservices' }
@{ Field = 'restoreBlocked'; DefId = 'ade_setupassistant_restore' }
@{ Field = 'appleIdDisabled'; DefId = 'ade_setupassistant_appleid' }
@{ Field = 'termsAndConditionsDisabled'; DefId = 'ade_setupassistant_termsandconditions' }
@{ Field = 'touchIdDisabled'; DefId = 'ade_setupassistant_touchfaceid' }
@{ Field = 'applePayDisabled'; DefId = 'ade_setupassistant_applepay' }
@{ Field = 'siriDisabled'; DefId = 'ade_setupassistant_siri' }
@{ Field = 'diagnosticsDisabled'; DefId = 'ade_setupassistant_diagnosticsdata' }
@{ Field = 'privacyPaneDisabled'; DefId = 'ade_setupassistant_privacy' }
@{ Field = 'screenTimeScreenDisabled'; DefId = 'ade_setupassistant_screentime' }
@{ Field = 'fileVaultDisabled'; DefId = 'ade_setupassistant_filevault' }
@{ Field = 'iCloudDiagnosticsDisabled'; DefId = 'ade_setupassistant_iclouddiagnostics' }
@{ Field = 'iCloudStorageDisabled'; DefId = 'ade_setupassistant_icloudstorage' }
@{ Field = 'accessibilityScreenDisabled'; DefId = 'ade_setupassistant_accessibility' }
@{ Field = 'autoUnlockWithWatchDisabled'; DefId = 'ade_setupassistant_unlockwithwatch' }
)
$macNewOnlyDefIds = @(
'ade_setupassistant_enablelockdownmode', 'ade_setupassistant_softwareupdate', 'ade_setupassistant_softwareupdatecompleted',
'ade_setupassistant_termsofaddress', 'ade_setupassistant_intelligence', 'ade_setupassistant_osshowcase', 'ade_setupassistant_appstore',
'ade_setupassistant_appearance'
)
$macSkippedFields = @(
"registrationDisabled (Registration screen removed from the new policy)"
"passCodeDisabled (Passcode screen not present on macOS policies)"
"zoomDisabled (Zoom screen removed from the new policy)"
"chooseYourLockScreenDisabled / displayToneSetupDisabled (classic 'Choose Your Look' screen has no confirmed new-policy equivalent - may correspond to the new Appearance screen, which was set to -NewFieldDefault instead - verify manually)"
"deviceNameTemplate (no macOS policy equivalent)"
"supervisedModeEnabled (ADE devices are always supervised under the new policy)"
"requireCompanyPortalOnSetupAssistantEnrolledDevices (handled automatically by modern authentication)"
"requestRequiresNetworkTether (no policy equivalent)"
"autoAdvanceSetupEnabled (no policy equivalent)"
"usePlatformSSODuringSetupAssistant (no policy equivalent)"
"adminAccountPassword (secret, never returned by Graph - set manually if used)"
)
# --- Per-platform settings builders -----------------------------------------
function Build-IosSettings {
param($SourceProfile, [string]$NewFieldDefault, [ref]$Skipped)
$settings = [System.Collections.Generic.List[object]]::new()
$affinityValue = if ($SourceProfile.requiresUserAuthentication) { 'ade_useraffinity_1' } else { 'ade_useraffinity_0' }
$children = @()
if ($SourceProfile.requiresUserAuthentication) {
if ($SourceProfile.enableAuthenticationViaCompanyPortal) {
$Skipped.Value.Add('enableAuthenticationViaCompanyPortal=true (legacy Company Portal auth has no policy equivalent - falling back to modern authentication)')
}
$awaitValue = if ($SourceProfile.awaitDeviceConfiguredConfirmation) { 'ade_modernauth_awaitfinalconfiguration_1' } else { 'ade_modernauth_awaitfinalconfiguration_0' }
$authChild = New-ChoiceInstance -DefId 'ade_authenticationmethod' -Value 'ade_authenticationmethod_2' `
-Children @((New-ChoiceInstance -DefId 'ade_modernauth_awaitfinalconfiguration' -Value $awaitValue))
$children = @($authChild)
}
$entry = $iosCatalog['ade_useraffinity']
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_useraffinity' -Value $affinityValue -InstTplId $entry.Inst -ValTplId $entry.Val -Children $children)))
$lockedValue = if ($SourceProfile.isMandatory) { 'ade_lockedenrollment_1' } else { 'ade_lockedenrollment_0' }
$entry = $iosCatalog['ade_lockedenrollment']
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_lockedenrollment' -Value $lockedValue -InstTplId $entry.Inst -ValTplId $entry.Val)))
$entry = $iosCatalog['ade_devicenametemplatechoices']
if (-not [string]::IsNullOrWhiteSpace($SourceProfile.deviceNameTemplate)) {
$nameChild = New-SimpleInstance -DefId 'ade_appledevicenametemplate' -Value $SourceProfile.deviceNameTemplate
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_devicenametemplatechoices' -Value 'ade_devicenametemplatechoices_1' -InstTplId $entry.Inst -ValTplId $entry.Val -Children @($nameChild))))
}
else {
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_devicenametemplatechoices' -Value 'ade_devicenametemplatechoices_0' -InstTplId $entry.Inst -ValTplId $entry.Val)))
}
$entry = $iosCatalog['ade_activatecellulardatachoices']
$cellValue = if ($NewFieldDefault -eq 'Show') { 'ade_activatecellulardatachoices_1' } else { 'ade_activatecellulardatachoices_0' }
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_activatecellulardatachoices' -Value $cellValue -InstTplId $entry.Inst -ValTplId $entry.Val)))
$Skipped.Value.Add('activatecellulardatachoices has no classic equivalent - applied -NewFieldDefault')
$entry = $iosCatalog['ade_setupassistant_department']
$settings.Add((New-TopLevelSetting (New-SimpleInstance -DefId 'ade_setupassistant_department' -Value $SourceProfile.supportDepartment -InstTplId $entry.Inst -ValTplId $entry.Val)))
$entry = $iosCatalog['ade_setupassistant_departmentphone']
$settings.Add((New-TopLevelSetting (New-SimpleInstance -DefId 'ade_setupassistant_departmentphone' -Value $SourceProfile.supportPhoneNumber -InstTplId $entry.Inst -ValTplId $entry.Val)))
foreach ($map in $iosScreenMap) {
$entry = $iosCatalog[$map.DefId]
$hidden = [bool]$SourceProfile.($map.Field)
$value = "$($map.DefId)_$(if ($hidden) { 0 } else { 1 })"
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId $map.DefId -Value $value -InstTplId $entry.Inst -ValTplId $entry.Val)))
}
$newValueSuffix = if ($NewFieldDefault -eq 'Show') { 1 } else { 0 }
foreach ($defId in $iosNewOnlyDefIds) {
$entry = $iosCatalog[$defId]
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId $defId -Value "${defId}_$newValueSuffix" -InstTplId $entry.Inst -ValTplId $entry.Val)))
}
foreach ($f in $iosSkippedFields) { $Skipped.Value.Add($f) }
return $settings
}
function Build-MacSettings {
param($SourceProfile, [string]$NewFieldDefault, [ref]$Skipped)
$settings = [System.Collections.Generic.List[object]]::new()
$affinityValue = if ($SourceProfile.requiresUserAuthentication) { 'ade_macos_useraffinity_1' } else { 'ade_macos_useraffinity_0' }
$children = @()
if ($SourceProfile.requiresUserAuthentication) {
if ($SourceProfile.enableAuthenticationViaCompanyPortal) {
$Skipped.Value.Add('enableAuthenticationViaCompanyPortal=true (legacy Company Portal auth has no policy equivalent - falling back to modern authentication)')
}
$children = @((New-ChoiceInstance -DefId 'ade_macos_authenticationmethod' -Value 'ade_macos_authenticationmethod_2'))
}
$entry = $macCatalog['ade_macos_useraffinity']
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_macos_useraffinity' -Value $affinityValue -InstTplId $entry.Inst -ValTplId $entry.Val -Children $children)))
# Nested account settings tree, confirmed against two live tenant policies
# (one with only a local admin account configured, one with only a
# primary account configured):
#
# awaitconfiguration
# -> createlocaladmin (Yes/No)
# -> createlocalprimary (No/Standard/Administrator) [always present]
# -> prefillaccountinfo (only when createlocalprimary != No)
# -> restrictediting, primaryaccountfullname, primaryaccountname
# -> adminaccountname, adminaccountfullname, hideusersgroups,
# adminaccountpasswordrotation [only when createlocaladmin = Yes]
$awaitValue = if ($SourceProfile.waitForDeviceConfiguredConfirmation) { 'ade_macos_awaitconfiguration_1' } else { 'ade_macos_awaitconfiguration_0' }
if ($SourceProfile.skipPrimarySetupAccountCreation) {
$primaryValue = 'ade_accountsettings_createlocalprimary_0'
}
elseif ($SourceProfile.setPrimarySetupAccountAsRegularUser) {
$primaryValue = 'ade_accountsettings_createlocalprimary_1'
}
else {
$primaryValue = 'ade_accountsettings_createlocalprimary_2'
}
$primaryChildren = @()
if ($primaryValue -ne 'ade_accountsettings_createlocalprimary_0') {
$prefillValue = if ($SourceProfile.dontAutoPopulatePrimaryAccountInfo) { 'ade_accountsettings_prefillaccountinfo_0' } else { 'ade_accountsettings_prefillaccountinfo_1' }
$restrictValue = if ($SourceProfile.enableRestrictEditing) { 'ade_accountsettings_restrictediting_1' } else { 'ade_accountsettings_restrictediting_0' }
$prefillChildren = @(
(New-ChoiceInstance -DefId 'ade_accountsettings_restrictediting' -Value $restrictValue)
(New-SimpleInstance -DefId 'ade_accountsettings_primaryaccountfullname' -Value $SourceProfile.primaryAccountFullName -ValTplId $macCatalog['ade_accountsettings_primaryaccountfullname'].Val)
(New-SimpleInstance -DefId 'ade_accountsettings_primaryaccountname' -Value $SourceProfile.primaryAccountUserName -ValTplId $macCatalog['ade_accountsettings_primaryaccountname'].Val)
)
$primaryChildren = @((New-ChoiceInstance -DefId 'ade_accountsettings_prefillaccountinfo' -Value $prefillValue -ValTplId $macCatalog['ade_accountsettings_prefillaccountinfo'].Val -Children $prefillChildren))
}
$primaryChild = New-ChoiceInstance -DefId 'ade_accountsettings_createlocalprimary' -Value $primaryValue -Children $primaryChildren
$hasAdmin = -not [string]::IsNullOrWhiteSpace($SourceProfile.adminAccountUserName)
$adminValue = if ($hasAdmin) { 'ade_accountsettings_createlocaladmin_1' } else { 'ade_accountsettings_createlocaladmin_0' }
$adminChildren = @($primaryChild)
if ($hasAdmin) {
$hideValue = if ($SourceProfile.hideAdminAccount) { 'ade_accountsettings_hideusersgroups_1' } else { 'ade_accountsettings_hideusersgroups_0' }
$adminChildren += (New-SimpleInstance -DefId 'ade_accountsettings_adminaccountname' -Value $SourceProfile.adminAccountUserName -ValTplId $macCatalog['ade_accountsettings_adminaccountname'].Val)
$adminChildren += (New-SimpleInstance -DefId 'ade_accountsettings_adminaccountfullname' -Value $SourceProfile.adminAccountFullName -ValTplId $macCatalog['ade_accountsettings_adminaccountfullname'].Val)
$adminChildren += (New-ChoiceInstance -DefId 'ade_accountsettings_hideusersgroups' -Value $hideValue -ValTplId $macCatalog['ade_accountsettings_hideusersgroups'].Val)
# Graph rejects createlocaladmin=Yes unless adminaccountpasswordrotation
# is present too - it's a required sibling, not optional. The classic
# field's shape isn't confirmed (it's null in every sample profile
# seen so far), so fall back to 0 (no rotation) unless it's already a
# plain number.
$rotationDays = 0
$rotationSetting = $SourceProfile.depProfileAdminAccountPasswordRotationSetting
if ($rotationSetting -is [int] -or $rotationSetting -is [long]) {
$rotationDays = [int]$rotationSetting
}
elseif ($rotationSetting) {
$Skipped.Value.Add('depProfileAdminAccountPasswordRotationSetting has a non-numeric shape - applied a default of 0 (no rotation), verify/set manually')
}
$adminChildren += (New-SimpleInstance -DefId 'ade_accountsettings_adminaccountpasswordrotation' -Value $rotationDays -ValTplId $macCatalog['ade_accountsettings_adminaccountpasswordrotation'].Val -ValueType 'Integer')
}
$adminEntry = $macCatalog['ade_accountsettings_createlocaladmin']
$adminChild = New-ChoiceInstance -DefId 'ade_accountsettings_createlocaladmin' -Value $adminValue -ValTplId $adminEntry.Val -Children $adminChildren
$entry = $macCatalog['ade_macos_awaitconfiguration']
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_macos_awaitconfiguration' -Value $awaitValue -InstTplId $entry.Inst -ValTplId $entry.Val -Children @($adminChild))))
$lockedValue = if ($SourceProfile.isMandatory) { 'ade_lockedenrollment_1' } else { 'ade_lockedenrollment_0' }
$entry = $macCatalog['ade_lockedenrollment']
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId 'ade_lockedenrollment' -Value $lockedValue -InstTplId $entry.Inst -ValTplId $entry.Val)))
if (-not [string]::IsNullOrWhiteSpace($SourceProfile.deviceNameTemplate)) {
$Skipped.Value.Add("deviceNameTemplate='$($SourceProfile.deviceNameTemplate)' (no macOS policy equivalent)")
}
$entry = $macCatalog['ade_setupassistant_department']
$settings.Add((New-TopLevelSetting (New-SimpleInstance -DefId 'ade_setupassistant_department' -Value $SourceProfile.supportDepartment -InstTplId $entry.Inst -ValTplId $entry.Val)))
$entry = $macCatalog['ade_setupassistant_departmentphone']
$settings.Add((New-TopLevelSetting (New-SimpleInstance -DefId 'ade_setupassistant_departmentphone' -Value $SourceProfile.supportPhoneNumber -InstTplId $entry.Inst -ValTplId $entry.Val)))
foreach ($map in $macScreenMap) {
$entry = $macCatalog[$map.DefId]
$hidden = [bool]$SourceProfile.($map.Field)
$value = "$($map.DefId)_$(if ($hidden) { 0 } else { 1 })"
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId $map.DefId -Value $value -InstTplId $entry.Inst -ValTplId $entry.Val)))
}
$newValueSuffix = if ($NewFieldDefault -eq 'Show') { 1 } else { 0 }
foreach ($defId in $macNewOnlyDefIds) {
$entry = $macCatalog[$defId]
$settings.Add((New-TopLevelSetting (New-ChoiceInstance -DefId $defId -Value "${defId}_$newValueSuffix" -InstTplId $entry.Inst -ValTplId $entry.Val)))
}
foreach ($f in $macSkippedFields) { $Skipped.Value.Add($f) }
return $settings
}
# --- Main --------------------------------------------------------------
$requiredScopes = @('DeviceManagementServiceConfig.ReadWrite.All')
if ($DeviceGroupName) { $requiredScopes += 'Group.Read.All' }
$context = Get-MgContext
if (-not $context -or @($requiredScopes | Where-Object { $_ -notin $context.Scopes }).Count -gt 0) {
Connect-MgGraph -Scopes $requiredScopes -NoWelcome
}
$deviceGroupId = $null
if ($DeviceGroupName) {
$groupFilter = "displayName eq '$($DeviceGroupName.Replace("'", "''"))'"
$groups = @(Get-GraphAll -Uri "beta/groups?`$filter=$([System.Uri]::EscapeDataString($groupFilter))&`$select=id,displayName")
if ($groups.Count -eq 0) { throw "Entra ID group '$DeviceGroupName' not found." }
if ($groups.Count -gt 1) { throw "Multiple Entra ID groups named '$DeviceGroupName' found - use a unique group name." }
$deviceGroupId = $groups[0].id
}
$tokens = Get-GraphAll -Uri 'beta/deviceManagement/depOnboardingSettings'
if ($TokenName) {
$tokens = @($tokens | Where-Object { $_.tokenName -eq $TokenName })
if ($tokens.Count -eq 0) { throw "Enrollment program token '$TokenName' not found." }
}
$profilesToMigrate = [System.Collections.Generic.List[object]]::new()
foreach ($token in $tokens) {
$allProfiles = Get-GraphAll -Uri "beta/deviceManagement/depOnboardingSettings/$($token.id)/enrollmentProfiles"
# Entries whose id is prefixed 'ECV2_' are Settings Catalog policies
# mirrored into this collection, not genuine classic profiles - skip them
# so an already-migrated policy is never "migrated" again.
$classicProfiles = @($allProfiles | Where-Object {
$_.id -notlike 'ECV2_*' -and
$_.'@odata.type' -in @('#microsoft.graph.depIOSEnrollmentProfile', '#microsoft.graph.depMacOSEnrollmentProfile')
})
if ($isBulkMode) {
foreach ($p in $classicProfiles) {
$profilesToMigrate.Add([PSCustomObject]@{ Token = $token; SourceProfile = $p })
}
}
else {
foreach ($p in ($classicProfiles | Where-Object { $_.displayName -eq $ProfileName })) {
$profilesToMigrate.Add([PSCustomObject]@{ Token = $token; SourceProfile = $p })
}
}
}
if (-not $isBulkMode -and $profilesToMigrate.Count -eq 0) {
throw "Classic enrollment profile '$ProfileName' not found (or it is already a Settings Catalog policy)."
}
if ($isBulkMode -and $profilesToMigrate.Count -eq 0) {
Write-Warning "No classic enrollment profiles found on token '$TokenName'."
}
foreach ($item in $profilesToMigrate) {
$token = $item.Token
$sourceProfile = $item.SourceProfile
$isIos = $sourceProfile.'@odata.type' -eq '#microsoft.graph.depIOSEnrollmentProfile'
$platformLabel = if ($isIos) { 'iOS' } else { 'macOS' }
Write-Output "--- Profile: $($sourceProfile.displayName) ($platformLabel, token '$($token.tokenName)') ---"
if (-not $isBulkMode -and $NewPolicyName) {
$targetName = $NewPolicyName
}
else {
$targetName = Get-DerivedPolicyName -OldName $sourceProfile.displayName
if (-not $targetName) {
if ($AllowIdenticalName) {
$targetName = $sourceProfile.displayName
}
elseif (-not $isBulkMode) {
throw "Profile name '$($sourceProfile.displayName)' does not follow the naming convention (no 'DeploymentProfile' segment) - pass -NewPolicyName, or -AllowIdenticalName to reuse the profile's name as-is."
}
else {
Write-Warning " Name does not follow the naming convention (no 'DeploymentProfile' segment) - skipping. Migrate it explicitly with -ProfileName and -NewPolicyName, or pass -AllowIdenticalName to reuse the profile's name as-is."
continue
}
}
}
$nameFilter = "name eq '$($targetName.Replace("'", "''"))'"
$existing = @(Get-GraphAll -Uri "beta/deviceManagement/configurationPolicies?`$filter=$([System.Uri]::EscapeDataString($nameFilter))&`$select=id,name")
if ($existing.Count -gt 0) {
if (-not $Force -and -not $PSCmdlet.ShouldContinue(
"A policy named '$targetName' already exists (id: $($existing[0].id)). Create a duplicate anyway?",
'Duplicate policy name')) {
Write-Warning " Skipped - policy '$targetName' already exists. Use -Force to create a duplicate anyway."
continue
}
}
$skipped = [System.Collections.Generic.List[string]]::new()
if ($isIos) {
$settings = Build-IosSettings -SourceProfile $sourceProfile -NewFieldDefault $NewFieldDefault -Skipped ([ref]$skipped)
$templateId = $iosTemplateId
}
else {
$settings = Build-MacSettings -SourceProfile $sourceProfile -NewFieldDefault $NewFieldDefault -Skipped ([ref]$skipped)
$templateId = $macTemplateId
}
$body = @{
name = $targetName
description = $sourceProfile.description
platforms = $platformLabel
technologies = 'enrollment'
templateReference = @{ templateId = $templateId }
creationSource = "DepTokenId_$($token.id)"
settings = $settings
}
if ($PSCmdlet.ShouldProcess($targetName, "Create Settings Catalog enrollment policy from '$($sourceProfile.displayName)'")) {
$created = Invoke-MgGraphRequest -Method POST -Uri 'beta/deviceManagement/configurationPolicies' `
-Body ($body | ConvertTo-Json -Depth 20) -ContentType 'application/json' -OutputType PSObject
Write-Output " Created policy '$($created.name)' (id: $($created.id))"
if ($deviceGroupId) {
$groupBody = @{
enrollmentTimeDeviceMembershipTargets = @(
@{ targetType = 'staticSecurityGroup'; targetId = $deviceGroupId }
)
}
Invoke-MgGraphRequest -Method POST -Uri "beta/deviceManagement/configurationPolicies('$($created.id)')/setEnrollmentTimeDeviceMembershipTarget" `
-Body ($groupBody | ConvertTo-Json -Depth 5) -ContentType 'application/json' | Out-Null
# retrieveEnrollmentTimeDeviceMembershipTarget is the real
# readback for this action (confirmed live - it's what the
# portal itself calls). Confirmed shapes: an empty
# enrollmentTimeDeviceMembershipTargetValidationStatuses array
# when no group is set, and one entry per target with its own
# validationSucceeded flag when a group is set.
$verify = $null
for ($attempt = 1; $attempt -le 3 -and -not $verify; $attempt++) {
try {
$verify = Invoke-MgGraphRequest -Method GET `
-Uri "beta/deviceManagement/configurationPolicies('$($created.id)')/retrieveEnrollmentTimeDeviceMembershipTarget" `
-OutputType PSObject -ErrorAction Stop
}
catch {
if ($attempt -lt 3) { Start-Sleep -Seconds 2 }
}
}
$match = $verify.enrollmentTimeDeviceMembershipTargetValidationStatuses | Where-Object { $_.targetId -eq $deviceGroupId }
if (-not $verify) {
Write-Warning " Could not verify enrollment-time device group '$DeviceGroupName' - check the policy in the portal to confirm it was applied."
}
elseif ($match -and $match.validationSucceeded) {
Write-Output " Set enrollment-time device group '$DeviceGroupName'"
}
else {
Write-Warning " Enrollment-time device group '$DeviceGroupName' was NOT applied, even though the request succeeded. This usually means the signed-in account/app lacks sufficient rights (e.g. Owner) on that group - set it manually in the portal instead."
}
}
}
if ($skipped.Count -gt 0) {
Write-Output ' Not migrated (configure manually if needed):'
foreach ($s in $skipped) { Write-Output " - $s" }
}
}
Summary
- Point the script at a single profile with
-ProfileName, or at a whole token with-TokenNameto migrate everything on it in one run. - Let the naming convention derive the new policy name automatically, or override it with
-NewPolicyName/-AllowIdenticalName. - Set the enrollment-time device group at the same time with
-DeviceGroupNameif you’re doing a single profile - the script verifies it actually landed and warns if the calling account didn’t have rights on the group. - Review the printed list of fields that couldn’t be migrated automatically and configure those manually.
- Continue with the rest of the migration from the previous article: test on a single device, set the policy as default, and reassign existing devices with
Set-AdeDevicesToEnrollmentPolicy.ps1.
The script isn’t a substitute for reviewing what gets created - it’s a substitute for clicking through the same wizard fifteen times.
